APC-2146

21.5" Meteor Lake Ultra 5 Panel PC With Anti-microbial Coating For Clinical Environments

INTRODUCTION

GET A QUOTE

White casing & sleek light weight design fit clinical professional image

Intel® 14th Gen Meteor Lake Ultra 5 125U processor supported

Front IP65 protection for easy cleaning

TPM 2.0 support for access control of critical patient data

GbE LAN ports & optional WiFi 6 connection for instant data transmission

Design of service window for easy storage expansion

Optional NFC & camera facilitate nursing & remote consult applications

Specification

Product Specification

Expand the section to view detailed technical specifications and features of the product.

System Information

Processor

Intel® 14th Gen Meteor Lake Ultra 5 125U Processor

System Memory

1 x 262-Pin DDR5 5600MHz SO-DIMM Socket Supports Up to 32GB

OS Support

Win10, Win11, Linux

H/W Status Monitor

CPU Temperature Monitoring
Voltage Monitoring

TPM

TPM 2.0

Expansion

M.2

1 x M.2 Key E 2230 support WiFi module

Storage

2.5” SATA3 SSD

Display

LCD Size

21.5"

Resolution

1920 x 1080

Luminance

250 cd/m2

Contrast Ratio

3000:1

Viewing Angle

178°/ 178°

I/O Ports

USB Port

2 x USB 3.2 Gen1
2 x USB 3.2 Gen2
1 x USB Type C

LAN Port

2 x RJ-45

HDMI

1 x HDMI

Audio Port

1 x Mic-in
1 x Line-out

LED Indicator

1 x Power LED

Other

1 x Power switch
1 x DC jack

Audio

Speaker Output

2 x 2W

Ethernet

LAN Chipset

1 x Intel® i226LM 2.5 Gigabit Ethernet Controller
1 x Intel® i226V 2.5 Gigabit Ethernet Controller

Ethernet Interface

10/100/1000/2500 Base-Tx GbE compatible

Wireless Communication

Bluetooth

Optional Wi-Fi + Bluetooth 5.3 USB Module, Intel Wi-Fi 6E AX210

WLAN

Optional Wi-Fi + Bluetooth 5.3 USB Module, Intel Wi-Fi 6E AX210

Data Collection

NFC

Optional NFC module

Camera

Optional 5.0M AF camera

Power Requirement

DC Input

+12V~+24V

DC Input Connector

Lockable DC jack

Adapter

Input: 100 ~ 240Vac/ 50 ~ 60Hz
Output: 90W adapter (24V/3.75A)

Certification

Certification Information

CE/ FCC class B/VCCI/UKCA

Mechanical & Environmental

Dimension (mm)

539.6x324.6x45.5

Construction

Plastic

Finishing

Anti-microbial

Mounting

VESA 75 x 75 / 100 x 100 mm

Color

White

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Operating Humidity

0% @ 90% Relative humidity, non-condensing

Storage Temp.

-10°C ~ 60°C (14°F ~ 140°F)

System Fan

Fanless

IP Rating

Front IP-65

Ordering Information

APC-2146-125-A2R
21.5" 1920x1080 Projected Capacitive Touch Panel PC (Plastics, White)Intel Ultra 5 125U/8GB memory/ USB Type C/ HDMI/ 4USB3/ 2LAN/Line-out/ MIC-in/ SPK/ 90W Adapter

EU Power Cord E1702031000R
US Power Cord E1702031833R
JP Power Cord E1712031834R
UK Power Cord E170P060380R
