RCC-BAT-GENI-02R
Geni-Tec Quad-Bay Charger
  • Specification
Product Specification
Expand the section to view detailed technical specifications and features of the product.

Bay Charger Spec

IEC Protection
Class I
(Internal Medical Grade Power Supply)
Input Voltage
90-264 V AC
Input Current
4.2 A @ 115 VAC, 60 Hz
2.1 A @ 230 VAC, 50 Hz
Input Frequency
47-63 Hz
Charge Current
3.75 A (max/bay)
Recharge Time
2.75 hrs (typ)
Operating Temperature
1°C ~ 40°C (34°F ~ 104°F)
Storage Temperature
-10°C ~ 35°C (14°F ~ 95°F)
Charge Method
Smart (Multi Chemistry)
Compliance
CE, FCC , EN/ES/IEC 60601-1
Net Weight
8.55 kg
Shipping Weight
10.05 kg
Installation method
Wall Mount
